What is the production of the laser cutting machine, what is the function of the laser cutting machine, I firmly believe that the management of the actual operation of the laser cutting machine will be very understanding, but some understand the laser cutting function to carry out laser cutting, but its detailed composition and function is likely not special master. Share with us a little common sense today.
Laser cutting machine
The actual operation control panel is used to control the entire operation process of the cutting equipment, and all system commands come from here. Laser cutting head Laser cutting head driving equipment is used to push the cutting head along the Z-axis orientation fitness movement in accordance with the program flow, by AC servo motor and screw or worm gear and other transmission equipment. The key parts include inner cavity, focusing lens seat, condenser mirror, capacitive sensor and auxiliary vapor nozzle.
A device with an adjustable and regulated power supply connected between a laser, a CNC lathe, and an energy supply system software. The key is to prevent the influence of the external power network and have the functional effect of the voltage regulator. Laser CNC machine tool Laser control CNC lathe to complete the X, Y, Z axis of fitness, at the same time also manipulate the power of the laser.
The laser generator and the external laser light path are the devices that create the laser light source. The external laser light path is a mapping reflection lens for the orientation required for laser orientation. In order to prevent common failures in the light path, all reflective lenses need to be maintained by the protective cover in various aspects, and enter a clean positive pressure maintenance vapor body to maintain the lens from environmental pollution.
Give and store compressed air. Remove the corner waste and waste products caused by production and processing. It includes a material gas tank and an auxiliary gas tank in the work of the laser cutting machine, which is used to fill the chemical gas of the laser fluctuation and provide an auxiliary vapor body for the cutting head. CNC lathe server part.
Laser cutting machine Part of a CNC lathe, part of the equipment that completes the operation of the X, Y, and Z axes, including a cutting operation platform. It is used to place the product workpiece to be cut and can be moved accurately and precisely according to the management program, generally driven by a stepper motor.
For refrigeration laser generators. Laser is the use of electromagnetic energy into solar energy equipment, such as CO2 vapor laser conversion rate is generally 20%, the remaining power is converted into heat. Cooling the circulating water takes away unnecessary heat to maintain the regular operation of the laser generator.
The dust and smoke caused by the production and processing are extracted, and the overworry is solved, so that the industrial waste gas meets the environmental protection standards. It is used to provide clean dry gas to the laser generator and the light path to maintain the routine operation of the path and the reflector lens.
