Application :
Used in industry of machinery,motor fitting ,sanitary,hardware,electronic components, metal arts and battery etc.
Model No: | W111-800 | W111-500 | W111-200 |
Laser Power: | 800W | 500W | 200W |
Wavelength: | 1070nm | 1070nm | 1070nm |
/Working Mode: | Continuous wave or modulation | ||
Beam Quality | 1.15 | 1.1 | 1.1 |
Output Power Stability: | ±2% | ±2% | ±2% |
Total Power: | ≤4kw | ≤3kw | ≤2kw |
Net Weight: | 350KG | 330KG | 320KG |
Welding Line Width | 0.04mm~0.2mm | ||
Driving Mode: | precision lead screw | ||
Working Area: | 200mm*200mm~300mm*600mm | ||
Operating temperature: | 15℃~35℃ | ||
Power Supply: | 220V/30A | ||
Cooling: | Water Cooling | ||
Dimension | 920*1120*1700mm | ||
